Anatomy

EGG
Each butterfly egg is surrounded by a hard outer shell, called the chorion, to protect the developing larva. The shell is lined with a layer of wax, which helps keep the egg from drying out. Each egg has one to many tiny funnel-shaped openings at one end, called micropyles. Since eggs get their hard shell before they are fertilized, this hole, which penetrates all the way through the shell, allows sperm to enter. The raised areas on an egg shell are called ridges. They are formed inside the female before she lays the egg. Butterfly and moth eggs vary greatly in shape.

SEM image of Monarch egg Diagram of Monarch egg




caterpillar diagramLARVA
Larvae have three distinct body parts. They have a head, and a body with a thorax and an abdomen. The head has a pair of very short antennae, mouthparts (upper lip, mandibles, and lower lip), and six pairs of very simple eyes, called ocelli. Even with all of these eyes, the caterpillar's vision is poor. The antennae help to guide the weak-eyed caterpillar and the maxillary palps, which are sensory organs, help direct food into the larva's jaws.

Each thoracic segment has a pair of jointed, or true legs, while some of the abdominal segments have false legs, or prolegs. There are usually five pairs of prolegs. The prolegs have tiny hooks on them that hold the larva onto its silk mat or leaf. The fleshy tentacles at the front and rear ends of Monarch larvae are not antennae, but they do function as sense organs.

Like other insects, Monarchs obtain oxygen through holes in the sides of their thorax and abdomen called spiracles. The spiracles are connected to a network of long airtubes called tracheae, which carry oxygen throughout the body.

Diagram of caterpillar head SEM image of caterpillar head

Use the diagram on the left to identify the ocelli, mandibles and head capsule in the photo on the right.




Diagram of pupaPUPA
When it pupates, a Monarch larva splits its exoskeleton and wiggles out of its larval skin. When this skin moves far enough down the body, the cremaster appears. The cremaster is a spiny appendage at the end of the abdomen. The Monarch hooks its cremaster into a silk pad spun by the larva just before pupation; it will hang from this until it emerges as an adult. The freshly exposed pupa is very soft and delicate until it hardens. You can see many different body parts on the pupa, including the wings, abdomen, legs and eyes.



Diagram of nectaring MonarchADULT
The body of an adult butterfly is divided into the same major parts as the larva-head, thorax, and abdomen. There are four main structures on the adult head: eyes, antennae, palpi, and proboscis.

A butterfly's relatively enormous compound eyes are made up of thousands of ommatidia [SEM photo (21 K)] each of which senses light and images. The two antennae and the two palpi, which are densely covered with scales, sense molecules in the air and gives butterflies a sense of smell. The straw-like proboscis is the butterfly's tongue, through which it sucks nectar and water for nourishment. When not in use, the butterfly curls up its proboscis [SEM photo (13 K)]

Three segments make up the thorax. Each segment has a pair of legs attached to it, while the second and third segments each have a pair of wings attached as well. The legs consist of six segments. They end in tarsi (singular, tarsus [SEM photo (13 K)]), which grip vegetation and flowers when the butterfly lands on a plant. Organs on the back of the tarsus "taste" sweet liquids. Monarchs (and other nymphalid butterflies) look like they only have four legs because the two front legs are tiny and curl up next to the thorax.

All butterflies and moths have four wings, two hindwings and two forewings. Small structures attach the wings to the thorax, and muscles attached to these structures move the wings. The butterfly can also move its wings by changing the shape of its thorax. Wing veins, tubes with thickened walls, contain trachea, nerves, and space for hemolymph to move through. Veins give the wings structure, strength, and support.

The abdomen consists of eleven segments, the last two or three of which are joined. On male Monarch butterflies you can see a pair of claspers on the end of the abdomen. These appendages grasp the female during mating.
